JB Tools Customer Satisfaction Guarantee: Although JB tools is often not an “authorized” re-seller of all the products it sells and is often not affiliated with the manufacturers or brands of the products it sells, JB Tools stands behind all of the products it sells, because the products JB Tools sells are genuine and authentic. Patented Skip Circuitry Test up to 9,990 RPM. Detachable 6-foot leads with metal inductive pickup. Heavy-duty ABS/Polycarbonate shockproof housing, molded boots, built-in hand guard for protection.

Advance Degrees (2 and 4 cycle): 0° to 90°.

Four function digital readout and easy-to-read backlit LCD: Their wide coverage, proven quality and competitive price make them the tool of choice for use on the vehicles of today and tomorrow.

#DIGITAL TIMING LIGHT FULL#

The INNOVA® Timing Lights include a full range of options designed to meet the needs of DIYers with many of the features that professional installers demand.

Patented Skip Circuitry Test up to 9,990 RPM.

Detachable 6-foot leads with metal inductive pickup.

Heavy-duty ABS/Polycarbonate shockproof housing, molded boots, built-in hand guard for protection.

#DIGITAL TIMING LIGHT MANUAL#

They all serve the same purpose but offer different RPM ranges, ability to operate a multi-spark system and offer features such as timing manual advance, a dwell meter, and the possible option to work on four-cylinder, six-cylinder, or eight-cylinder engines. What brand manufacturers offer automotive timing lights?Īutomotive timing lights come in three styles: inductive, digital, and self-powered. Not every timing light is compatible with MSD systems, so be sure to check that the one you want can meet these requirements before purchasing. To properly measure this sequence, the timing light must be able to show the beginning of the sequence.

#DIGITAL TIMING LIGHT SERIES#

Typically, the distributor only provides a single spark for an ignition sequence, but in MSD systems, there are a series of them disbursed at a specific timing. How do timing lights help multiple spark distribution systems (MSD)?

Units with a dwell meter measure for how long the coil is being charged and allow for prevention of pitting or burning due to an accurately set point gap.

Adjustment knobs coupled with a tachometer allow for more precise timing measurement at different RPMs.

Adjustment knobs that allow for the timing to be read at different RPMs are available on some models.

It should be able to read both two-cycle and four-cycle engines.

The standard timing lights come with a xenon light tube that is able to read timing when the vehicle engine is at idle.

Knowing this allows adjustments to be made via manipulation of the distributor cap to make the spark plugs fire before or after the piston has reached the top dead center, depending on the malfunction or issue that needs to be fixed.

By aiming this strobe light in the proper place, usually the crankshaft pulley, you will be able to read the degree markings on it, which are indicative of where the crankshaft is in its rotation and the respective pistons. Inductive timing lights, when connected properly to the car's engine and battery, detect the electricity every time the plug fires, and every time the plug fires, the timing light shoots a beam of light. The light is powered by the vehicle it is being used to test. The light can be a stroboscope that may use a simple neon lamp or a xenon strobe lamp that provides brighter light and better use in daylight or in shop lighting. Timing lights are diagnostic tools used to observe ignition timing in vehicles with distributors and are available as self-contained units or as a part of a more comprehensive engine analytical tool.

See Your Car's Diagnostics More Clearly With Automotive Timing Lights
